Gas and Liquid High Pressure Relief Valve in Brass and Stainless Steel

2300 Series

Our 2300 series high pressure relief valves offer exellent repeatable and dependability. Factory set and 100% tested for accuracy.

2300-1MP
1/8 MNPT x 1/8" FNPT
Max Pressure 3600 psi
Orifice Size .215
Flow Coefficient: Cv: Consult Factory
Cracking Pressure
Currently Available		 10-2400
Technical Data
2300-2MP
1/4" MNPT x 1/4" FNPT
Max Pressure 3600 psi
Orifice Size .281
Flow Coefficient: Cv: Consult Factory
Cracking Pressure
Currently Available		 10-2400
Technical Data
2300-3MP
3/8" MNPT x 3/8" FNPT
Max Pressure 3600 psi
Orifice Size .359
Flow Coefficient: Cv: Consult Factory
Cracking Pressure
Currently Available		 10-2400
Technical Data
2300-4MP
1/2" MNPT x 1/2" FNPT
Max Pressure 3600 psi
Orifice Size .518
Flow Coefficient: Cv: Consult Factory
Cracking Pressure
Currently Available		 10-2400
Technical Data
