2300 Series
The 2300 Series Relief Valves are designed for high-pressure performance with a positive seat design, zero leakage, tamper-proof adjustment, and 100% leak testing for dependable, precision relief control.
1/8″ MNPT x 1/8″ FNPT
Max Pressure: 3600 PSI
Orifice Size: 0.215
Flow Coefficient cv: Consult Factory
Crack Pressures Available (PSI):
10-2400
1/4″ MNPT x 1/4″ FNPT
Max Pressure: 3600 PSI
Orifice Size: 0.281
Flow Coefficient cv: Consult Factory
Crack Pressures Available (PSI):
10-2400
3/8″ MNPT x 3/8″ FNPT
Max Pressure: 3600 PSI
Orifice Size: 0.359
Flow Coefficient cv: Consult Factory
Crack Pressures Available (PSI):
10-2400
1/2″ MNPT x 1/2″ FNPT
Max Pressure: 3600 PSI
Orifice Size: 0.518
Flow Coefficient cv: Consult Factory
Crack Pressures Available (PSI):
10-2400
